Hand-guided thermoplastic applicator

WT 40/50
WT 40/50 - Image 2
WT 40/50 - Image 3
WT 40/50 - Image 4
WT 40/50 - Image 5
WT 40/50 - Image 6
  1. WT 40/50
  2. WT 40/50 - Image 2
  3. WT 40/50 - Image 3
  4. WT 40/50 - Image 4
  5. WT 40/50 - Image 5
  6. WT 40/50 - Image 6

Description

Machine type Hand-guided thermoplastic applicator WT 40/50
Traction drive hand guided
Wheels 3-fold solid rubber, d=200 mm, on request pneumatic tyres
Working width for marker units up to 50 cm
Heating gas burner
Additional equipment Glass bead equipment
Empty weight approx. 50 kg
Dimensions Length x width x height approx. 1,00 m x 1,00 mm x 1,00 mm
Technical modifications and errors excepted, illustrations similar resp. partly including special accessories.
State of art: 01.11.2014_e
